Product Number: 1437-100-L25
The 1437 Series Non-Locking Wing Knob Compression Latch (SKU: 1437-100-L25) is a die-cast zinc alloy quarter-turn latch finished in black powder coat, designed to secure enclosure panels where tool-free hand operation is required. With a sealed IP65 rating, it is suited to applications where resistance to dust and water jets is necessary.
The housing and cylinder are constructed from zinc die-cast alloy with a black powder-coated finish. The cam and shaft are manufactured from mild steel with a zinc-plated finish. The wing knob design allows hand-tightening and release without tools, making it practical for panels requiring regular access.
The latch accommodates a panel cutout of 19.5 x 19.5 mm and is compatible with panel thicknesses from 1 mm to 16 mm. The grip range covers 25.4–41.1 mm and 52.6–68.3 mm, offering flexibility across a range of enclosure depths. The cam option is described as a range available, and the latch is supplied in a non-locking configuration. A bright chrome finish variant is also available within the 1437 Series.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Range available |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 25.4-41.1mm, 52.6-68.3mm |
| IP Rating | IP65 |
| Lock Types | Non Locking |
| Material | Zinc Die |
| Model | 1437 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. The 1437-100-L25 requires a panel cutout of 19.5 x 19.5 mm.
A. The latch is compatible with panel thicknesses from 1 mm to 16 mm.
A. The latch covers two grip ranges: 25.4–41.1 mm and 52.6–68.3 mm.
A. The 1437-100-L25 carries an IP65 rating, providing protection against dust ingress and water jets.
A. The housing and cylinder are die-cast zinc alloy with a black powder-coated finish. The cam and shaft are mild steel with a zinc-plated finish.
A. No — the 1437-100-L25 is a non-locking compression latch. It secures via quarter-turn compression without a key or lock cylinder.
A. Yes — a bright chrome finish variant is available within the 1437 Series, and a range of cam options is also available.
