Product Number: 1421-05
The 1421-05 is a mini compression latch from the 1421 series, featuring a slotted recess actuation and an adjustable grip range to suit varied panel assemblies. The latch is finished in black powder coat over a die cast zinc alloy body, with a mild steel zinc plated shaft, combining corrosion resistance with robust mechanical performance. The latch carries a sealed IP65 rating, making it suitable for enclosures and panels exposed to dust and water ingress. A cam is included with the latch. Panel cutout dimensions are 13.5 x 16 mm and the latch accommodates panel thicknesses from 1 to 10 mm. The adjustable grip range spans from 3.2 mm to 28.6 mm across eight selectable increments: 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm. A bright chrome finish variant is also available within the 1421 series; contact PartsForMachines for further information.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| IP Rating | IP65 |
| Lock Types | Slotted Recess |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1421 |
| Panel Cutout | 13.5x16mm |
| Panel Thickness | 1 - 10mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-08 | 1421-20 | 1422-013 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Size | 3mm | ||||
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 16mm |
| Size Range | Up to 10mm | ||||
A. The 1421-05 requires a panel cutout of 13.5 x 16 mm.
A. The latch accommodates panel thicknesses from 1 mm to 10 mm.
A. The 1421-05 offers eight adjustable grip range increments: 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm.
A. The 1421-05 carries an IP65 ingress protection rating.
A. The body is die cast zinc alloy with a black powder coated finish. The shaft is mild steel zinc plated. A cam is included.
A. Yes — a bright chrome finish is available within the 1421 series. Contact PartsForMachines directly for further information on that variant.
A. Yes, a cam is included with the 1421-05 compression latch.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
