Product Number: 1439-110-L15
The 1439 series compression latch (SKU: 1439-110-L15) is a key locking T-handle compression latch finished in black powder coat, designed for secure panel closure applications requiring IP65-rated environmental protection. The CH751 key cylinder is supplied with keys included, and the adjustable grip range of 11.4–27.2 mm and 66.3–76.2 mm accommodates panel thicknesses from 1 to 20 mm, making it suitable across a wide range of enclosure and cabinet installations.
The housing and cylinder are constructed from die-cast zinc alloy with black powder coat finish, while the cam and shaft are mild steel zinc plated. A cam is included as standard. The square panel cutout requirement is 19.5 x 19.5 mm.
The IP65 rating confirms protection against dust ingress and low-pressure water jets, supporting use in demanding workshop, industrial, and outdoor enclosure environments where a reliable, tamper-resistant fastening solution is required.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Lock Types | Key Locking CH751 (Keys supplied) |
|---|---|
| Colour/Finish | Black Powder Coated |
| Material | Die Cast Zinc Alloy |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 20mm |
| Grip Range | 11.4-27.2 & 66.3-76.2mm |
| IP Rating | IP65 |
| Cam Option | Cam included |
| Model | 1439 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. This latch uses a CH751 key cylinder. Keys are supplied with the latch as standard.
A. The 1439 series latch accepts panel thicknesses from 1 to 20 mm, with a grip range of 11.4–27.2 mm and 66.3–76.2 mm.
A. A square cutout of 19.5 x 19.5 mm is required.
A. This latch carries an IP65 rating, providing protection against dust ingress and low-pressure water jets.
A. The housing and cylinder are die-cast zinc alloy with a black powder coat finish. The cam and shaft are mild steel with zinc plating.
A. Yes, a cam is included as standard with this latch.
A. We accept all major credit and debit cards, along with PayPal.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
