Product Number: 1409-110-3520
The 1409-110-3520 is a Model 1409 key locking T-handle compression latch supplied with CH751 keys. Designed to secure enclosure panels and cabinet doors where a reliable, lockable fastening is required, it accepts a panel cutout of Ø20 mm and accommodates panel thicknesses from 1 to 27 mm with a grip range of 35.3 to 51 mm, making it suitable for a range of cabinet and enclosure wall thicknesses.
The handle and housing are constructed from die-cast zinc alloy with a black powder-coated finish, offering a durable, corrosion-resistant exterior. The cam mechanism is mild steel zinc plated and is included as standard. The latch carries a sealed IP65 rating, confirming resistance to dust ingress and low-pressure water jets — appropriate for demanding workshop or industrial enclosure environments.
The CH751 key locking mechanism means the latch can only be operated with the supplied keys, providing a basic access control function suitable for toolboxes, electrical enclosures, and similar cabinets. The adjustable grip range of 35.3 to 51 mm allows the latch to be set correctly for the specific panel assembly without requiring separate adjustment hardware.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Lock Types | Key Locking CH751 (Keys supplied) |
|---|---|
| Colour/Finish | Black Powder Coated |
| Material | Die Cast Zinc Alloy |
| Panel Cutout | Ø20 |
| Panel Thickness | 1 - 27mm |
| Grip Range | 35.3-51mm |
| IP Rating | IP65 |
| Cam Option | Cam included |
| Model | 1409 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1421-04 | 1421-05 | 1421-08 | 1421-20 | 1422-013 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Size | 3mm | ||||
| Grip Range | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| Panel Thickness | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 16mm |
| Size Range | Up to 10mm | ||||
A. The latch uses a CH751 key locking mechanism and keys are supplied as standard.
A. The latch requires a panel cutout of Ø20 mm and accommodates panel thicknesses from 1 to 27 mm.
A. The adjustable grip range is 35.3 to 51 mm.
A. The latch carries an IP65 ingress protection rating.
A. The handle and housing are die-cast zinc alloy with a black powder-coated finish. The cam is mild steel zinc plated.
A. The cam is included with the latch.
