Product Number: 02-017B
The CCL 02-017B is a 12V normally open twin output (twin contact) mini relay with a moulded bracket, designed as a general-purpose switching component for automotive, commercial vehicle, and light electrical circuits requiring dual independent outputs.
The relay operates on a 12V supply and features five 6.3mm terminals arranged to provide twin contact outputs in a normally open configuration. Each output is rated to a continuous load of 25A (closed), with a peak load capacity of 50A per contact - delivering a combined continuous capability of 2x25A and a combined peak of 2x50A. The integrated moulded bracket simplifies panel or chassis mounting without the need for additional hardware.
The twin output design makes the 02-017B well suited to applications where a single switched input must simultaneously control two independent circuits - such as dual horn installations, split auxiliary lighting circuits, or twin-feed switching duties. The normally open contact arrangement means both output circuits remain open (inactive) until the relay coil is energised.
No vehicle fitment data is published for this relay at present. Suitability should be confirmed against the circuit requirements of the target application - specifically supply voltage, continuous load per circuit, and terminal connector compatibility (6.3mm).
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 5 Pin normally open contact twin output twin contact Mini Relay. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD | 2 x 25A |
| PEAK LOAD | 2 x 50A |
| BRACKET TYPE | Moulded Plastic |
| TERMINAL SIZES | 5 x 6.3mm` |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|
| Technical Specification | |
|---|---|
| PRODUCT NUMBER | 02-017 |
A. Each output contact on the 02-017B is rated at 25A continuous load (closed) and 50A peak load (closed), giving a combined rating of 2×25A continuous and 2×50A peak across the twin outputs.
A. The relay has five terminals, each measuring 6.3mm, covering the coil supply, coil earth, common, and the two switched output contacts.
A. It is a normally open relay. Both output circuits remain open (inactive) until the relay coil is energised, at which point the contacts close and the outputs are activated.
