Product Number: 1402-50100-30
The Metrol 1402-50100-30 is a non-locking quarter turn lock featuring a wing handle design with a 50mm barrel height, finished in bright chrome. Manufactured under the Metrol 1402 model series, it is suited to panel-mounting applications requiring a quarter turn fastening solution without a locking mechanism.
The handle and housing are constructed using zinc alloy die casting with a bright chrome finish. The fitted cam is in zinc-plated mild steel finish. The product is also available in black powder coated finish; the specific cam option is selected from the available range.
The lock accepts a panel cutout of 20.1 x 20.1 mm and accommodates panel thicknesses from 1 mm to 36 mm, providing considerable installation versatility. It carries IP65-grade weather sealing, confirming resistance to dust ingress and low-pressure water jets — suitable for industrial enclosures and control panels operating in demanding environments.
Manufactured by Metrol. No contents information is available for this SKU. No warranty information is provided in the source data.
The 1402-50 Non Locking Wing Handle Quarter Turn Lock with 50mm Grip Height Bright Chrome is a durable cam lock designed for secure closure of meter boxes, panel boards, CNC housings, machinery parts. Built with a smooth quarter-turn mechanism, it provides reliable locking for cabinets, access panels, enclosures.
Available with triangle key, double-bit insert, key-locking, key-retaining, this cam lock fits standard UK cut-outs and supports both new installations and replacements.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Manufacturer | Metrol |
|---|---|
| Lock Types | Non Locking |
| Colour/Finish | Bright Chrome |
| Material | Die Cast Zinc Alloy |
| Panel Cutout | 20.1x20.1mm |
| Panel Thickness | 1 - 36mm |
| Barrel Height | 50mm |
| IP Rating | IP65 |
| Cam Option | Range available |
| Model | 1402 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
1301-50 Non Locking T Handle Lock with 50mm Grip Height Black Textured Powder Coated
£16.42
£16.10
2% OFF
|
||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1301-50100-20 | 1301-50100-30 | 1301-50110-20 | 1301-50110-30 | 1311-50100-20 |
| Type | Lock | Lock | Lock | Lock | Lock |
| Size | 50mm | 50mm | 50mm | 50mm | 50mm |
| Finish | Chrome | Chrome | |||
| Size Range | 26-50mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm |
A. The 1402-50100-30 is a non-locking quarter turn lock. It uses a wing handle to operate the quarter turn mechanism without a keyed or locking function.
A. The barrel height is 50mm.
A. The required panel cutout is 20.1 x 20.1mm.
A. The lock accommodates panel thicknesses from 1mm to 36mm.
A. The 1402-50100-30 carries an IP65 rating, indicating protection against dust ingress and low-pressure water jets.
A. The handle and housing are die cast zinc alloy with a bright chrome finish. The cam is mild steel with a zinc plated finish.
A. Yes — the 1402 series is available in bright chrome and black powder coated finishes. A range of cam options is also available within the series.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
