Product Number: 31978
Achieving clean, chip-free cuts in brittle materials is a persistent challenge in professional workshop environments. The Draper 31978 TCT Triple Chip Grind Circular Saw Blade addresses this directly through its triple chip grind geometry, which cuts a groove with slanting sides. This design combines balanced cutting force, low tooth drag and free chip flow to eliminate chipping in brittle materials such as laminates and chipboards — a common source of waste and rework. The blade is constructed from steel with Tungsten Carbide-Tipped (TCT) teeth that are high-quality and precision-ground, contributing to robustness and consistent performance across a wide range of materials. An anti-kickback design prevents the blade from feeding too quickly, reducing the risk of loss of control during operation. The blade is designed for use on all woods, aluminium, non-ferrous metals, laminates and plastics. Key specifications include a 255mm diameter, 30mm bore, 100-tooth configuration and a kerf of 2.8mm. The rake angle is 5° and the maximum rated speed is 5,200rpm. The blade weighs 0.650kg. It is compatible with most 255mm circular saws fitted with a 30mm bore, including Draper Stock Nos. 90170 and 79899. The blade meets EN847-1 standard. Supplied as a single blade.
This triple chip grind Tungsten Carbide-Tipped (TCT) circular saw blade cuts a groove with slanting sides. This design combines a balanced cutting force, low tooth drag and free chip flow, eliminating chipping in brittle materials such as laminates and chipboards. The high-quality precision-ground carbide teeth make the blade robust. The anti-kickback design prevents the blade feeding too quickly. Designed for use on all woods, aluminium, non-ferrous metals, laminates and plastics. Compatible with most 255mm circular saws with a 30mm bore including Stock No. 90170 and 79899. EN847-1 Standard.
Product Key Feature:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specialising in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalogue of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Material | Steel with TCT teeth |
|---|---|
| Diameter | 255mm |
| Bore | 30mm |
| Tooth count | 100T |
| Kerf | 2.8mm |
| Grind | Triple Chip Ground |
| Rake angle | 5° |
| Max. speed | 5,200rpm |
| Weight | 0.650kg |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price | |
|---|---|---|---|---|---|
|
79899 | Draper 79899 Double Bevel Sliding Compound Mitre Saw, 255mm, 2000W | 1 Unit |
£182.43
£178.85
|
Add |
|
90170 | Draper 90170 Sliding Compound Mitre Saw, 255mm, 1800W | 1 Unit |
£149.84
£146.90
|
Add |
Standard Delivery: £4.99
Next Day Delivery Available
Delivery Estimate: 2 to 3 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|
| Technical Specification | |
|---|---|
| PRODUCT NUMBER | 31881 |
| Type | Circular Saw Blade |
| Size | 30mm |
| Size Range | 26-50mm |
A. The blade is designed for use on all woods, aluminium, non-ferrous metals, laminates and plastics, as confirmed in the product specification.
A. The triple chip grind geometry cuts a groove with slanting sides. This combines balanced cutting force, low tooth drag and free chip flow, eliminating chipping in brittle materials such as laminates and chipboards.
A. The blade has a 255mm diameter, 30mm bore, 100-tooth configuration, a 2.8mm kerf, a 5° rake angle and a maximum rated speed of 5,200rpm. It weighs 0.650kg.
A. The blade is compatible with most 255mm circular saws fitted with a 30mm bore, including Draper Stock Nos. 90170 and 79899.
A. Yes. The blade incorporates an anti-kickback design that prevents the blade from feeding too quickly during cutting.
A. Yes. The Draper 31978 circular saw blade meets the EN847-1 standard.
