Product Number: MSG65/521
The Primo XM from Grammer is an innovative seating concept. It is the first seat for forklift trucks and construction machines with a low-profile suspension, optionally available with pneumatic or mechanical suspension and quick weight adjustment. The broad, ergonomic seat cushions and the height and angle adjustable armrests support the body as optimal as the backrest, where the angle is adjustable from -5° to +30°.
The Primo XM also supports when driving backward: the asymmetrical backrest is tapered on the right side which makes it easier to turn around in the seat. As the first low-profile compact seat the Primo is equipped with a lumbar support for the sensitive lumbar region. The backrest height is adjustable in 13 steps up to 170 mm, according to the body height or work situation.
Product Features:
| Mounting / rail centres | Not stated by manufacturer |
|---|---|
| Slide rail travel | Not stated by manufacturer |
| Seat width | 470 mm |
| SIP (ISO 5353) | Not stated by manufacturer |
| Bracket / fitting | Not stated by manufacturer |
| Suspension type | Mechanical suspension |
| Compressor / voltage | n/a (no compressor) |
| Suspension stroke | 60 mm |
| Weight adjustment | 45 - 170 kg (manual) |
| Height adjustment | Not stated by manufacturer |
| Fore/aft adjustment | 210 mm |
| Backrest | Adjustable backrest angle |
| Trim | Not stated by manufacturer |
| Standard features | Non-adjustable shock absorber; Mechanical lumbar support |
| Optional features | Document box; Armrests height-adjustable; Fore/aft isolator (not for earth-moving machinery); Backrest extension; Restraint system; Seat heating; OPS |
| Standards / compliance | Not stated by manufacturer |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
MSG65-521.pdf
|
Open Now |
Standard Delivery: £7.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Grammer Seating - Grammer MSG20 - Mechanical Suspension Seat, PVC - Adjustable Backrest
£372.02
£364.73
2% OFF
|
Grammer Seating - Grammer MSG85/521 - Mechanical Suspension Seat, 210mm Slide Rail Adjustment
£1,073.33
£1,052.28
2% OFF
Free delivery in UK Mainland
|
|
| Technical Specification | |||
|---|---|---|---|
| PRODUCT NUMBER | Grammer MSG20 | MSG85/521 | US MGV35 |
| Machine Type | Construction & Plant | Forklift & Materials Handling | Construction & Plant |
| Suspension | Mechanical | Mechanical | Mechanical |
| Max Operator Weight | Up to 135kg | Up to 135kg | Over 150kg |
| Trim | PVC (waterproof) | Fabric | PVC (waterproof) & Fabric options |
| OPS Switch | Optional | No | Optional |
A. The manufacturer does not publish mounting centres for the MSG65/521. Measure your existing seat's bolt spacing and compare with your machine before ordering. Suited applications: forklift & materials handling.
A. For the MSG65/521: The manufacturer does not list an operator presence switch for this model. If your forklift requires seat switch sensing, check compatibility before ordering. Switch wiring (normally open/closed) and connectors vary by truck - match to your machine's circuit.
A. The manufacturer states a weight adjustment range of 45 - 170 kg (manual). Set the suspension to the operator's weight for correct ride and vibration performance.
A. The MSG65/521 uses mechanical suspension with 60 mm of travel. Suspension isolates the operator from machine vibration; set it to the operator's weight where adjustment is provided.
