Product Number: 05771
Variations
Weld and steel from the same machine. Lift-TIG start provides clean arc ignition.
Designed with the latest IGBT inverter technology platform. Multi-functional; HF TIG, Lift ARC TIG, and MMA/ARC processes.
Features:
Suitable for welding mild steel and stainless steel.
Fan-assisted cooling manages operating temperature during sustained welding. Automatic thermal overload protection cuts output if the machine exceeds safe temperature, with IP21S protection rating for workshop use. For operators comparing TIG welders for steel and stainless steel, the 05771 delivers DC TIG output with lift or HF arc start. TIG welding produces the cleanest, most precise welds — ideal for visible joints and thin materials. TIG mode requires tungsten electrodes and shielding gas (Argon or Argon/Helium mix) for clean, precise welds on steel and stainless steel. Replacement consumables for the 05771 are available at PartsForMachines.com.
Additional Information:
The SIP HG2200P TIG/ARC Inverter Welder is a professional-grade dual-purpose inverter designed with a TIG Pulse facility which provides easier precision welding across a variety of applications and a 9-stage parameter adjustment program.About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| ITEM NO | 05771 |
|---|---|
| Input Supply | 230v (16A) |
| Output Current | 5A - 200A (TIG) / 20A - 200A (ARC) |
| Output Voltage | 10.2v - 18v (TIG) / 20.8v - 28v (ARC) |
| Duty Cycle | 200A @ 60% (TIG) / 200A @ 60% (ARC) |
| Electrode Diameter | Ø 1.6mm - 4mm |
| Protection Level | IP21S |
| Insulation Class | Class H |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price | |
|---|---|---|---|---|---|
|
05016 | Draper 5016 Expert HI-TORQ® 6 Point Impact Socket, 1/4" Sq. Dr., 11mm | 1 Unit |
£9.83
£9.64
|
Add |
Pro Tips for Buying Welding Machines: Types, Uses, and Choosing the Perfect Fit Introduction:Welding, the art of joining metals through heat and precision, has evolved significantly with the advent of adv...
Standard Delivery: UK Mainland Free
Next Day Delivery Available
Delivery Estimate: 2 to 4 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
SIP 05695 WELDMATE® PRO 200A DC TIG/ARC Inverter Welder
£441.12
£432.47
2% OFF
Free delivery in UK Mainland
|
SIP 05691 WELDMATE® PRO 200A DV ARC/TIG Inverter Welder
£253.64
£248.67
2% OFF
Free delivery in UK Mainland
|
SIP 05740 WELDMATE® AUTOPLUS 200A MIG/ARC/TIG Synergic Welder
£417.13
£408.95
2% OFF
Free delivery in UK Mainland
|
Sealey INVMIG200 Inverter Welder MIG, TIG & MMA 200A
£647.07
£634.38
2% OFF
Free delivery in UK Mainland
|
|
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 05695 | 05691 | 05740 | INVMIG200 | TIG160 |
| Output Current | 10A - 200A (TIG) / 10A - 160A (MMA) | ARC | 50A - 200A (MIG) / 20A - 200A (ARC) / 20 | ||
| Input Supply | 230v (16A) | 230v (16A) / 110v (16A) | 230v (16A) | ||
| Output Voltage | ARC | 16.5v - 24v (MIG) / 20.8v - 28v (ARC) / | |||
| Voltage (V) | 230 | 230 | 230 | 230 | 230 |
| Weight (kg) | 0.7 | 15 | 38 | ||
A. The 05771 supports TIG welding, ARC/MMA stick welding. Output spans 5A - 200A (TIG) / 20A - 200A (ARC) across all modes. Suitable for mild steel.
A. The 05771 requires a 230V / 16A supply. If you are unsure whether your supply is adequate, consult a qualified electrician before installation.
A. The 05771 has a duty cycle of 200A @ 60% (TIG) / 200A @ 60% (ARC). Duty cycle is measured over a 10-minute period — a 60% duty cycle means 6 minutes of continuous welding followed by a 4-minute cool-down. Operating at lower amperages increases available run time.
A. The 05771 accepts electrodes from Ø 1.6mm - 4mm in diameter. Compatible rod types include rutile and basic electrodes for mild steel, and specialist stainless and cast iron rods where relevant.
A. The 05771 is primarily designed for workshop use. Check the specification for weight and portability details.
A. The 05771 is primarily suited to mild steel.
A. Yes. The 05771 is fitted with automatic thermal overload protection that cuts output if the machine exceeds safe operating temperature. It will restart automatically once it has cooled. Operating within the rated duty cycle minimises the frequency of thermal interruptions.
A. The 05771 does not include a foot pedal as standard. A compatible foot pedal may be available as an optional accessory — check the product listing for compatible accessories.
A. TIG produces the cleanest, most precise welds — ideal for stainless steel, thin sheet, and visible joints where appearance matters. ARC/MMA is faster for thicker sections and suits outdoor or on-site work. The 05771 lets you switch between TIG and ARC to match the job.
