Product Number: BAT412025081
Variations
Deep-cycle and standby applications demand a battery that withstands repeated discharge without premature capacity loss. The Victron Energy AGM Super Cycle 12V 25Ah (BAT412025081) is engineered specifically to address this challenge, offering substantially greater cycle life than standard AGM batteries in a compact, maintenance-free VRLA format.
Victron Energy's AGM Super Cycle technology employs a high-purity lead-calcium alloy plate construction with a recombinant valve-regulated design, yielding a design life of 7–10 years. The very low internal resistance of the AGM construction makes this battery particularly well suited to high-current discharge applications including inverters, bow thrusters, and winches, where sustained delivery under load is critical.
Physical dimensions are 200mm (L) × 95mm (W) × 210mm (H), with a weight of 6.45 kg. The battery features threaded insert (M5) terminals. Polarity configuration should be confirmed directly from the product label prior to installation. No direct cross-reference part numbers are held on record for this SKU.
This battery is available in additional capacity variants: BAT412038081 and BAT412060082, enabling system designers to select the appropriate amp-hour rating for their application." Supplied with a 2-year manufacturer warranty. Stocked and dispatched from the UK. "Standard delivery: 1–3 working days within UK mainland. 30-day returns.
VRLA AGM: design life 7-10 years VRLA GEL: design life 12 years
The AGM range has very low internal resistance making them particularly suitable for high current discharge applications such as for inverters, thrusters and winches. The GEL model range offers best deep cycle durability and overall longer life. The use of high purity materials and lead calcium grids ensure that for both AGM and GEL products have particularly low self-discharge so that they will not go flat during long periods without charge. Both ranges are supplied with M8 drilled, flat copper terminals ensuring best possible connection contact and eliminating the need for battery terminals. The batteries are compliant with both CE and UL specifications in ABS fireproof containers and come with Victron's 2 year world-wide warranty.
Key Feature:Designed for Off-Grid applications, balancing dependable starting with steady power delivery.
Uses:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specialising in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalogue of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Brand | Victron Energy Blue Power |
|---|---|
| Voltage | 12V |
| Capacity AH (C20) | 25Ah |
| Cold Cranking Amps (EN) | |
| L × W × H | 200mm × 95mm × 210mm |
| Warranty period | 2 Years |
| Weight (Kg) | 6.45 |
| Capacity AH (C5) | |
| Capacity AH (C10) | |
| Capacity AH (C100) | |
| Marine Cranking Amps (MCA) | |
| Watt-Hours (WH) | |
| Length (mm) | 200 |
| Width (mm) | 95 |
| Height Inc. Terminal (mm) | 210 |
| Terminal Placement | |
| Terminal Type | |
| Hold Down | |
| Case Size | |
| ETN Number | |
| TTNR |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Expert Guidelines for Preserving Your Heavy Equipment Battery Heavy machinery, including forklifts, bulldozers, and excavators, relies on robust batteries to minimize downtime and maximize operational availability. These batteries must endure even more challenging conditions than typical automotive batteries. Moreover,...
Standard Delivery: £7.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | S4000 | S4001 | S4018 | S4019 | S4020 |
| Voltage | 12 | 12 | 12 | 12 | 12 |
| Capacity (AH) | 44 | 44 | 40 | 40 | 45 |
| Cold Cranking Amps (EN1) | 420 | 440 | 330 | 330 | 330 |
| Terminal Type | 1 | 1 | 3 | 3 | 3 |
| Length | 175 | 207 | 187 | 187 | 238 |
| Width | 175 | 175 | 127 | 127 | 129 |
| Height | 190 | 175 | 227 | 227 | 227 |
| Show More | |||||
A. The SKU is BAT412025081 and the full product name is Victron Energy AGM Super Cycle Battery 12V 25Ah (M5).
A. This battery uses threaded insert M5 terminals, which are suitable for bolted connections commonly used in marine, leisure, and industrial installations.
A. Polarity is not fixed by the product specification data held for this SKU. Victron Energy advises that polarity must be confirmed directly from the label on the individual battery unit prior to installation.
A. The rated capacity is 25Ah measured at the C20 rate (20-hour discharge). Capacity figures at C5, C10, and C100 rates are not published for this SKU.
A. Due to its very low internal resistance, this battery is particularly suited to high-current discharge applications such as inverters, bow thrusters, and winches, as well as general deep-cycle leisure and standby use.
A. The AGM Super Cycle range carries a design life of 7–10 years under correct operating and charging conditions, as stated by Victron Energy.
A. The AGM Super Cycle technology is broadly compatible with start-stop applications; however, suitability for a specific vehicle must be verified from the product label and vehicle manufacturer requirements before fitment.
A. Yes. The AGM Super Cycle 12V range includes BAT412038081 and BAT412060082, offering higher amp-hour capacities for applications requiring greater energy storage.
A. Standard delivery to UK mainland addresses is 1–3 working days. A 30-day returns policy applies to this product.
A. The battery measures 200mm (length) × 95mm (width) × 210mm (height including terminal) and weighs 6.45 kg.
