Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200

Product Number: NS-20-40-200_A14

£233.68 £229.10

BUY NOW

ADD TO CART

Variations

Gas Strut - Variable Force - NS-20-40-200_A1

Gas Strut - Variable Force - NS-20-40-200_A2

Gas Strut - Variable Force - NS-20-40-200_A3

Gas Strut - Variable Force - NS-20-40-200_A4

Gas Strut - Variable Force - NS-20-40-200_A5

Gas Strut - Variable Force - NS-20-40-200_A6

Gas Strut - Variable Force - NS-20-40-200_A7

Gas Strut - Variable Force - NS-20-40-200_A8

Gas Strut - Variable Force - NS-20-40-200_A9

Gas Strut - Variable Force - NS-20-40-200_A10

Gas Strut - Variable Force - NS-20-40-200_A11

Gas Strut - Variable Force - NS-20-40-200_A12

Gas Strut - Variable Force - NS-20-40-200_A13

Gas Strut - Variable Force - NS-20-40-200_A15

Gas Strut - Variable Force - NS-20-40-200_A16

The majority of a gas spring is made of metal and therefore can be recycled. If you are going to dispose of a gas spring yourself, e.g. if it has been damaged or has otherwise become unusable, bear in mind the following:

Depressurise the gas strut by drilling a 3 mm hole 20 mm from the tube end with it fixed in the vertical position and the piston rod down and in the fully extended position. Wear protective goggles, protective clothing and ear defenders when doing this as the spring will make a noise when pierced and you may be exposed to small amounts of oil and metal fragments.

Nitrogen is an inert gas and is neither explosive nor toxic. Drain the oil through the drilled hole by pressing in and pulling out the piston rod repeatedly if necessary. Recycle the waste oil in accordance with local regulations.

The gas strut can now be taken to a metal recycling centre in accordance with local regulations.

BUY NOW

ADD TO CART

Body Diameter	40mm
Extended Length	511mm
Force Progression	45%
Force Range	300 - 5000N
Rod Diameter	20mm
Stroke	200mm
Rod End Fitting	C4 - M14 Clevis Fork, 56mm length, 14mm eye
Rod End Bracket	-
Body End Fitting	B16 - M14 Ball Joint, 45mm length, M14 stud
Body End Bracket	-

BUY NOW

ADD TO CART

Engine Parts	Product Number	Product Name	Recommended Units	Product Price

BUY NOW

ADD TO CART

Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200	Open Now

BUY NOW

ADD TO CART

Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Use promo code "RMPK1" to get Additional 1% OFF

Question about this product? Click here

Compare with Similar products	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £221.67 £217.32 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £343.65 £336.91 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £341.17 £334.48 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £329.16 £322.71 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £221.67 £217.32 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £329.16 £322.71 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £329.16 £322.71 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £334.63 £328.07 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £216.20 £211.96 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £349.11 £342.26 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £343.65 £336.91 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £231.20 £226.67 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 700mm, Extended Length 1511mm, Metrol - NS-20-40-700 £338.18 £331.55 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £233.68 £229.10 2% OFF ADD	Compare Gas Strut - Variable Force, Stroke 200mm, Extended Length 511mm, Metrol - NS-20-40-200 £219.20 £214.90 2% OFF ADD
Technical Specification
PRODUCT NUMBER	NS-20-40-200_A5	NS-20-40-700_A12	NS-20-40-700_A24	NS-20-40-700_A16	NS-20-40-200_A2	NS-20-40-700_A4	NS-20-40-700_A3	NS-20-40-700_A6	NS-20-40-200_A3	NS-20-40-700_A7	NS-20-40-700_A9	NS-20-40-200_A16	NS-20-40-700_A14	NS-20-40-200_A8	NS-20-40-200_A4

General

Q 1. What Are Gas Struts and How Do They Work?

A. Gas struts are self-contained, maintenance-free units that use pressurised gas and oil to deliver smooth, controlled motion for lids, hatches, and doors.

Q 2. What Can Gas Struts and Springs Be Used For?

A. Gas struts are versatile units used across industries for lifting, counterbalancing, damping, and supporting doors, hatches, machinery, vehicles, and more.

Q 3. Which Gas Strut is Right for You?

A. With various options available, the right gas strut can be selected based on material, size, or your specific application using our category filters.

Q 4. How to Select a Gas Strut for a New Application?

A. Use our free gas strut design service and provide full application details, as we can't recommend a strut without accurate specifications.

Q 5. Which Gas Strut End Fittings and Brackets Should Be Used?

A. We recommend using ball joints where possible to reduce side loading and extend strut life—use our free gas strut design service for tailored guidance.

Q 6. How Are Gas Struts Installed?

A. Install gas struts piston-rod down in a single plane using ball joints, keep them in a relaxed state, tighten end fittings, and rotate the cylinder if alignment is needed.

Q 7. Fitting brackets

A. Remove the retaining clip, secure the socket to the strut, press it onto the bracket ball until it clicks, then reinsert the clip to lock it in place.
