Product Number: 02-024
The CCL 02-024 is a 12V changeover mini relay with built-in resistor protection, designed for use in automotive, commercial vehicle, plant and agricultural electrical circuits where reliable switching and coil protection are required in a compact form factor.
The relay operates on a 12V supply and features five 6.3mm terminals in a changeover (SPDT) configuration, allowing a single switching device to control both normally-open and normally-closed circuit paths. Resistor protection is integrated within the relay to suppress voltage spikes generated when the coil de-energises, helping to protect sensitive electronic control units and surrounding components from back-EMF damage.
The CCL 02-024 is rated for a continuous load of 40A on the normally-open contact and 30A on the normally-closed contact, with peak load capacities of 80A and 60A respectively. These ratings make it suitable for driving higher-current loads such as auxiliary lighting, horns, cooling fans and motor circuits. The 6.3mm terminal pitch is a widely used standard in 12V vehicle wiring harnesses, ensuring compatibility with common relay connectors and relay bases.
As a general replacement component, the 02-024 is suited to installations where a changeover relay with integrated coil suppression is specified. No fitment data is available from source; suitability should be confirmed against the circuit requirements of the target application.
The CCL 02-024 is supplied as a single relay unit. Manufactured by CCL.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 5 Pin changeover Mini Relay with Resistor protection. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD (OPEN) | 40A |
| CONTINUOUS LOAD (CLOSED/SWITCHED) | 30A |
| PEAK LOAD (OPEN) | 80A |
| PEAK LOAD (CLOSED / SWITCHED) | 60A |
| BRACKET TYPE | None |
| TERMINAL SIZES | 5 x 6.3mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|
| Technical Specification | |
|---|---|
| PRODUCT NUMBER | 02-024B |
A. The 02-024 is rated for a continuous load of 40A on the normally-open (open) contact and 30A on the normally-closed (closed) contact. Peak load ratings are 80A and 60A respectively.
A. Yes. The CCL 02-024 is a changeover (SPDT) relay, meaning it provides both a normally-open and a normally-closed switching path from a single device.
A. The integrated resistor protection suppresses voltage spikes produced when the relay coil de-energises. This helps protect sensitive electronic control units and other components from back-EMF damage.
