Product Number: 2120-640-90
The 2120-640-90 is a 64x64mm screw-on hinge manufactured from Nylon 6 GF30 — a glass fibre reinforced polyamide — finished in black, with a mild steel zinc plated pin. It is suited to industrial enclosure, panel, and equipment applications where a robust, corrosion-resistant polymer hinge is required.
Despite its non-metallic construction, this hinge delivers substantial load-bearing capability: an axial load capacity of 349 kg per hinge and a radial load capacity of 535 kg per hinge. The 6.5mm through holes accept standard fasteners, and the unhanded orientation means the hinge can be fitted to either left-hand or right-hand applications without modification. The Model 2120 series is a recognised screw-on platform used in enclosure manufacturing and industrial cabinetry.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Colour/Finish | Black |
|---|---|
| Material | Nylon 6 GF30 |
| Size | 64x64mm |
| Axial Load Capacity | 349Kg per hinge |
| Radial Load Capacity | 535Kg per hinge |
| Model | 2120 |
| Orientation | Unhanded |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 2408-02-01 | 2408-02-304 | 2407-011-01 | 2407-011-304 | 2407-012-304 |
| Type | Hinge | Hinge | Hinge | Hinge | Hinge |
| Size | 65mm | 65mm | 67mm | 67mm | 67mm |
| Material | Zinc plated steel | Stainless steel | Zinc plated steel | Stainless steel | Stainless steel |
| Finish | Zinc | Zinc | |||
| Size Range | 51-100mm | 51-100mm | 51-100mm | 51-100mm | 51-100mm |
A. The hinge body is manufactured from Nylon 6 GF30, a glass fibre reinforced polyamide, finished in black. The pin is mild steel with a zinc plated finish.
A. This hinge is rated at 349 kg axial load capacity and 535 kg radial load capacity per hinge.
A. The 2120-640-90 features 6.5mm through holes for fastener attachment.
A. No. The 2120-640-90 has an unhanded orientation, meaning it is suitable for both left-hand and right-hand applications without the need to specify a hand at the point of order.
A. The hinge measures 64x64mm.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
