Product Number: 1245-414-203
The Metrol 1245-414-203 is a tooling secured lever latch finished in black powder coat, designed to securely close and hold panels, doors, and covers whilst allowing quick, controlled access when required. Suitable for use in industrial equipment, electrical enclosures, cabinets, and machinery housings, this latch helps prevent accidental opening caused by vibration or handling and supports repeatable day-to-day operation.
The latch is constructed in die cast zinc for the handle, housing, and trigger, with mild steel zinc plated fixing components, providing a combination of structural integrity and corrosion resistance. The black-coated finish contributes to durability in demanding environments. Salt spray tested to over 300 hours, it is rated IP40 for protection against solid particle ingress.
The 1245-414-203 accepts a universal 5x90mm panel cut-out and is suited to panels between 21 and 31mm in thickness, with a grip range of 1 to 14mm. The tooling secured lock type ensures that access is controlled, making it appropriate for enclosures and housings where unauthorised or accidental opening must be prevented. A one-year guarantee is provided as standard.
Latches are access hardware components designed to securely close and hold panels, doors, and covers while still allowing quick, controlled access when needed. Commonly used in industrial equipment, electrical enclosures, cabinets, and machinery housings, they help prevent accidental opening from vibration or handling and support repeatable day-to-day operation. Available in multiple styles and mounting options, latches can be selected to match different access frequency, security, and installation requirements.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Manufacturer | Metrol |
|---|---|
| Lock Types | Tooling Secured |
| Colour/Finish | Black Powder Coated |
| Material | Mild Steel Zinc Plated Fixing Components, Die Cast Zinc Alloy |
| Panel Cutout | 5x90mm |
| Panel Thickness | 21 - 31mm |
| Grip Range | 1-14mm |
| IP Rating | IP40 |
| Model | 1245 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1245-214-201 | 1245-214-202 | 1245-314-201 | 1245-314-202 | 1245-414-204 |
| Type | Lever Latch | Lever Latch | Lever Latch | Lever Latch | Lever Latch |
| Size | 14mm | 14mm | 14mm | 14mm | 14mm |
| Grip Range | 1-14mm | 1-14mm | 1-14mm | 1-14mm | 1-14mm |
| Panel Thickness | 1 - 11mm | 11 - 21mm | 1 - 11mm | 11 - 21mm | 31 - 41mm |
| Size Range | 11-25mm | 11-25mm | 11-25mm | 11-25mm | 11-25mm |
A. This lever latch is designed for panels between 21 and 31mm thick and accepts a grip range of 1 to 14mm.
A. The latch uses a universal 5x90mm panel cut-out.
A. The latch carries an IP40 rating, providing protection against solid particle ingress.
A. The handle, housing, and trigger are manufactured from die cast zinc alloy. The fixing components are mild steel zinc plated. The exterior finish is black powder coat.
A. The 1245-414-203 is a tooling secured lever latch, meaning a tool is required to operate the latch and gain access — making it suitable for enclosures where controlled access is needed.
A. This latch has been salt spray tested to over 300 hours.
